TELWIN Inverter Plasma Cutting Machine SUPERIOR PLASMA 70 (816170)
Overview
Inverter, compressed air plasma cutting system, , with contact striking of pilot arc.
Allows a rapid, distortion-proof cutting, grid cutting and gauging of all conductive materials such as steel, stainless steel, galvanized steel, aluminum, copper, brass etc
It allows interfacing with automated cutting systems.
Features
Easy to carry- High cutting current stability
- User-friendly easy to read and adjust digital panel
- Remote control
- Thermostatic, overvoltage, undervoltage, overcurrent, torch start circuit, phase failure protections.
Complete with torch
Tech Spec
| Model | SUPERIOR PLASMA 70 (816170) |
|---|---|
| Main Voltage | 230/400 V, 50/60Hz, 3 phase |
| Current range | 20 – 50 / 20 – 70A |
| Max current | 50A-30% / 70-30% |
| Max no load voltage | 310 / 325V |
| Max absorbed current | 16 / 13A |
| Max absorbed power | 5.5/8.5 kW |
| Efficiency | 90% |
| Power factor (cosφ) | 0.9 |
| Max cutting thickness | 25mm |
| Compressed air capacity | 200 L/min |
| Compressed air pressure | 4-5 bar |
| Protection degree | IP23 |
| Dimensions | 47 x 19 x 35.5 cm |
| Weight | 15.8 kg |
