WESTLAKE Gear Head Drilling & Milling Machine ( ZX7045 )
RM21,700.00
Categories: Metal Working, Bench Drilling, Milling, Tapping, Drilling, Milling & Tapping
Tags: DRILLING MACHINE, MILLING MACHINE, WESTLAKE
Description
Product Description
Main Features:
1. 45mm gear shift square column drilling & milling machine. Deluxe stand is optional.
2. Wide range of speed.
3. Gear driving, gear quench, high carrying capacity.
4. Great torsional moment.
5. High gear precision, low noise.
Tech Spec
Model | ZX7045 |
Max. Drilling Capacity | 45mm |
Width Of Face Milling | 80mm |
Diameter Of Vertical Milling | 28mm |
Spindle Travel | 120mm |
Distance Spindle Axis To Column Surface | 260mm |
Max.Distance Spindle Nose To Worktable | 475mm |
Spinder Taper | MT4 or R8 |
Spindle Speeds Range | 95-1600rpm |
Spinder Speeds | 6 |
Dimension Of Table | 820 x 240mm |
Travel Of Worktable | 550 x 200mm |
Overall Height | 1040mm |
Headstock Travel | 410mm |
Power | 750w x 415v |
Measurement | 1120 x 820 x 1130mm |
G.W | 340kg |
