WESTLAKE Drilling & Milling Machine ( ZX7032 )
RM15,200.00
Description
Product Description
Main Features:
1. 32mm bench-type drilling & milling machine. Deluxe stand is optional.
2. Belt driving, low noise.
3.The belt will skid when the machine is over load.
4. High precision.
5. The spindle of spindle have hand feeding and jiggle feeding.
Tech Spec
| Model | ZX7032 |
| Max. Drilling Capacity | 31.5mm |
| Width Of Face Milling | 80mm |
| Diameter Of Vertical Milling | 22mm |
| Spindle Travel | 130mm |
| Distance Spindle Axis To Column Surface | 202mm |
| Max.Distance Spindle Nose To Worktable | 450mm |
| Spinder Taper | MT3 or R8 |
| Spindle Speeds Range | 100-2150rpm |
| Spinder Speeds | 12 |
| Dimension Of Table | 730 x 210mm |
| Travel Of Worktable | 500 x 175mm |
| Overall Height | 1100mm |
| Headstock Travel | 315mm |
| Power | 1500w x 415v |
| Measurement | 1080 x 770 x 1200mm |
| G.W | 330kg |
