TLP Single-Acting Cylinder
Description
Single-acting General Purpose Cylinders
Working pressure: 700bar
●Designed for use in all positions.
●High strength alloy steel for durability.
●Chrome plated piston resists wear and corrosion.
●Dust wiper on piston rod reduces contamination.
●Baked enamel finish for increased corrosion resistance.
●All cylinders are proof tested to 125% of capacity before leaving our factory.
●10-100 ton cylinder bores are roller burnished to harden the surface and make it smoother.
●10-200 ton cylinder models are spring return, 250-1000 ton cylinder models are load return.
●Each cylinder has an HH-II R2 3/8 male half coupler and dust cap.
●Each cylinder has a flat grooved saddle.
Tech Spec
| MODEL | CAPACITY | Stroke | OIL CAPACITY | MATCHING PUMP | CLOSED HEIGHT A | EXTENDED HEIGHT B | OUTSIDE DIA. D | INSIDE DIA. E | PISTON DIA. F | G.W |
| HHYG-1050 | 10 Ton | 50 mm | 85 | HHB-700A / HHB-700B | 122 mm | 172 mm | 68 mm | 45 mm | 36 mm | 3.1 kg |
| HHYG-10100 | 10 Ton | 100 mm | 169 | HHB-700A / HHB-700B | 172 mm | 272 mm | 68 mm | 45 mm | 36 mm | 4.4 kg |
| HHYG-10150 | 10 Ton | 150 mm | 254 | HHB-700A / HHB-700B | 222 mm | 372mm | 68 mm | 45 mm | 36 mm | 5.7 |
| HHYG-2050 | 20 Ton | 50 mm | 157 | HHB-700A / HHB-700B | 126 mm | 176 mm | 78 mm | 60 mm | 45 mm | 4 kg |
| HHYG20100 | 20 Ton | 100 mm | 311 | HHB-700A / HHB-700B | 176 mm | 276 mm | 78 mm | 60 mm | 45 mm | 5.3 kg |
| HHYG-20150 | 20 Ton | 150 mm | 465 | HHB-700A / HHB-700B | 226 mm | 376 mm | 78 mm | 60 mm | 45 mm | 6.6 kg |
| HHYG-3050 | 30 Ton | 50 mm | 237 | HHB-700A / HHB-700B | 137 mm | 187 mm | 103 mm | 75 mm | 65 mm | 7.9 kg |
| HHYG30100 | 30 Ton | 100 mm | 471 | HHB-700A / HHB-700B | 187 mm | 287 mm | 103 mm | 75 mm | 65 mm | 10.7 kg |
| HHYG-30150 | 30 Ton | 150 mm | 705 | HHB-700A / HHB-700B | 237 mm | 387 mm | 103 mm | 75 mm | 65 mm | 13.5 kg |
| HHYG5050 | 50 Ton | 50 mm | 389 | HHB-700A / HHB-700B | 147 mm | 197 mm | 123 mm | 95 mm | 70 mm | 11.6 kg |
| HHYG-50100 | 50 Ton | 100 mm | 768 | HHB-700A / HHB-700B | 197 mm | 297 mm | 123 mm | 95 mm | 70 mm | 14.9 kg |
| HHYG50150 | 50 Ton | 150 mm | 1147 | HHB-700A / HHB-700B | 247 mm | 397 mm | 123 mm | 95 mm | 70 mm | 18 kg |
| HHYG-10050 | 100 Ton | 50 mm | 779 | HHB-700A / HHB-700B | 182 mm | 232 mm | 168 mm | 135 mm | 90 mm | 25.7 kg |
| HHYG-100100 | 100 Ton | 100 mm | 1530 | HHB-700A / HHB-700B | 232 mm | 332 mm | 168 mm | 135 mm | 90 mm | 30.6 kg |
| HHYG-100150 | 100 Ton | 150 mm | 2281 | HHB-700A / HHB-700B | 282 mm | 432 mm | 168 mm | 135 mm | 90 mm | 35.5 kg |
