TELWIN AUTO BATTERY CHARGER Doctor Charger 50, 6/12/24V 230V
Overview
Multifunctional, electronic battery charger (BATTERY MANAGER) for complete maintenance of WET, GEL, AGM, MF, PbCa, EFB, Li 6V/12V/24V batteries and for support activities in interventions, including diagnostics, on vehicles carried out in workshops, body shops and dealers.
The Pulse Tronic technology guarantees optimal battery charging over 8 phases.
Features
Automatic charging and maintenance in Pulse Tronic based on the technology of the selected battery.- BOOST function for quick charge
- COLD function for charging and maintenance of batteries at low temperatures
- stable POWER SUPPLY for diagnostics (BSU) when charging the battery (SUPPLY) and maintain the battery health of vehicles on display in showrooms
- Batteries maintenance through RECOVERY function, to recover sulphated or very low batteries; and EQUALIZATION function to restore optimal functionality with periodic regeneration
- TESTER for checking terminal voltage, starting capacity (CCA) and vehicle alternator operation
- Start aid;
- Cable extension compensation function
- LCD display;
- Protection against overcharge, short circuit and polarity reversal
- Fit with PFC device
- Complete with cable with clamps
Tech Spec
| Model | Doctor Charge 50 (807613) |
|---|---|
| Mains frequency | 50/60 Hz |
| Single phase mains voltage | 230 V |
| Charging voltage | 6/12/24 V |
| Charging absorbed power | 610 W |
| Effective charging current | 45/45/23A |
| Rated charge curr.EN60335-229 | 40/40/20A |
| Start current 1V/C EN60335-2-29 | 40 (BOOST)A |
| Start current 1V/C EN60335-2-29 | 50 A |
| Min. rated reference capacity | 10 Ah |
| Max. rated reference capacity | 600 Ah |
| Protection degree | IP 33 |
| Dimensions | 9.2 x 20 x 33 cm |
| Weight | 3.77 kg |
