TELWIN Spot Welding Machine: Modular 400
RM5,600.00
Features
TELWIN Spot Welding Machine: Modular 400.
1. automatic regulation of the spot welding current and time according to the material thickness
2. choice between continuous and pulse operation (suitable for sheets with high yield points – high stress)
3. arms pressure adjustable from 40 kg to 120 kg (with arms L= 120 mm)
4. handgrip made out of thermic isolating material
5. thermal protection.
Tech Spec
| Model | Modular 20 TI (230V) | Digital Modular 230 | Digital Modular 400 |
|---|---|---|---|
| Code | 823015 | 823016 | 823017 |
| Mains Voltage | 230 V (1-ph) | 400 V (2-ph) | |
| Mains Frequency | 50 / 60 Hz | ||
| Max Spot-Welding Current | 5800 A | 6900 A | |
| Max No Load Voltage | 2 V | 2.5 V | |
| Max Absorbed Power | 6 kW | 13 kW | |
| Rated Power X=50% | 1.2 kW | 2.3 kW | |
| Mains Fuse | 16 A | 25 A | 16 A |
| Power Factor (cosphi) | 0.9 | ||
| Max Weld.Thickness On 2 Sheets | 1 + 1 mm | 2 + 2 mm | |
| Duty Cycle | 1.5 % | ||
| Protection Degree | IP20 | ||
| Dimensions | 44x10x18.5 cm | ||
| Weight | 9.88 kg | 10.5 kg | 10.3 kg |
