METABO Crosscut Mitre Saw KGS 254 I PLUS
Features
- Maximum flexibility when sawing thanks to rotating table and inclinable saw head on both sides
- Sliding function for wide work pieces.
- Quiet induction motor with motor brake and overload protection – maintenance-free and robust.
- Easy transport thanks to ergonomically-designed handles and saw head lock
- Superb dust extraction capability thanks to a dual extraction port design aligned closely to the work piece.
- Metabo Quick for changing saw blades without tools
- Soft start for long service life of motor and drive
- Fast and precise setting of common angles using stop points
- Sliding high rear fence profiles for safe sawing
- Material clamp for secure fixing of the work piece from the top or front
- Integrated, pull-out table width extensions made from die-cast aluminium
- Depth guide for easy creation of grooves
- All scales and operating elements are visible from the working position and can be operated intuitively
Tech Spec
| Model | KGS 2541 Plus (0102540200) |
| Dimension | 930 x 690 x 590 | 3.1 x 2.3 x 2 ft |
| Maximum cutting width 90 /45 | 305 / 214 mm | 12/8 7/16″ |
| Maximum cutting depth | 90 /54 mm |3 9/16 / 2 1/8″ |
| Straight cut 90/90 | 305 x 90 mm |12 x 3 9/16 /2 1/8″ |
| Double mitre 45/45 | 214 x 54 mm | 8 7/16 x 2 1/8″ |
| Turntabe setting left/ right | 47/ 60 |
| Saw blade tilt left /right | 46 / 22.5 |
| Saw Blade | 254 x 30 mm | 10 x 1.181″ mm |
| Rated input power | 1800 W |
| Rated input power S6 20% | 1800 W |
| No-load speed | 4650 /min |
| Revolutions at rated load | 4650 /min |
| Cutting speed | 62 m/s | 203 ft/s |
| Weight | 32.5 kg | 71.6 lbs |
| Cable length | 2.2 m | 7 ft |
Scope of Delivery
- Carbide saw blade (60 teeth)
- 2 Table length extensions
- Material clamp
- Connection piece 630316000
