COME-UP Longer Rope Compact Winch
Categories: Material Handling, Electric Winches, Winches
Tag: COMEUP
Description
COME-UP Longer Rope Compact Winch
Lightweight and compact design for easy installation
Double mechanical ratchets brake provide instant and safe braking
Operates on standard household power supply
Wire rope comes with a safety-latch weight hook
Enclosed drum flange prevents ropes becoming trapped between drum and support castings
Emergency stop function switch is available upon request
Best solution for wind energy turbines for efficient and economical operation at great heights
Tech Spec
MODEL | CAPACITY | Motor ( IP44 ) | Lifting Speed | Gear Ratio | Wire Rope | Braking Menthods | Drum Length | Drum Dia. | Drum Flange Dia. | Mounting Bolts Pattern | Packing Diamension | G.W |
CWL200L | 200kg | 1.5kw x 230v | 11-16 m /min | 240:01:00 | 5mm x 71m | For Motor ( Electromagnetic ) For Gear ( Machanical Ratchet ) | 147mm | 95 mm | 190 mm | 197 x 94 x 207 x 135mm | 545 x 395 x 350 mm | 35kg |
CWL-301L | 300kg | 2.3kw x 230v | 16-25 m/min | 110:01:00 | 6mm x 60m | For Motor ( Electromagnetic ) For Gear ( Machanical Ratchet ) | 147mm | 95mm | 190mm | 197 x 94 x 207 x 135mm | 630 x 395 x 350 mm | 42kg |
