COME-UP Compact Strap Hoist ( CSH-250 )
RM3,800.00
Description
COME-UP Compact Strap Hoist
- Light Weight and Compact Design. Allow easy installation.
- High Strength Strap offers smoother winding. Eliminates load rotation problem with wire rope or chain. Straps do not chip or spark.
- Equipped with upper limit switch to prevent over lifting.
- Suitable for work place requires stricter levels of cleanliness.
- Triple brakes design provide slip free operation
- Permanent magnetic motor features constant output and low noise level.
- Can operate on standard domestic power supply and equip with industrial plug
- Standard Compliance: CE Machinery Directive 2006/42/EC, CE EMC Directive 2014/30/EU , Safety of machinery EN 60204-32:2008
Tech Spec
| Model | Capacity | Power | Duty Cycle | Gear Ratio | Speed | Lifting Height | Brake | Drum | Strap | Control | Protection | Dimension | G.W |
| CSH-250 | 250kg | 300w x 230v | 25% ED, 63% Load | 216:01:00 | 5-6 m/min | 5m | Spring applied drag brake + Drag brake + Motor dynamic brake | 90 x 140 x 53mm | 50mm x 1.2mm x 5.5m ( breaking strength 1500kg ) | 5m ( Emergency stop Button ) | Upper Limit switch | 453 x 329 x 355mm | 20.5kg |
Warning:
- The hoist is not intended to be used in any manner for the movement or lifting of personnel.
- The strap winding on the drum shall remain 3 wraps on the drum and must not be used to ensure safe operation.
- Strap may break under unnoticed conditions. Operate the strap hoist away from the strap operating area and perform regular maintenance.
Warranty:
Each new hoist is guaranteed against defects in workmanship and material defect for a period of 6 months from date of purchase.
Strap are not included under warranty.
